- 01 Key Feature
Project Anywhere Instantly from Short Distances
Project an 80-inch image from 73 cm5 (2.40 ft) and avoid shadows on screen. Compact 4.9 kg (10.8 lbs) body is highly portable and easy to install with Digital Zoom Extender and Image Shift6 function. Start work instantly: project from standby in about one second7 and hold attention with quiet 24 dB8 operation.
- 02 Key Feature
Efficient Reliability with Minimal Maintenance
SOLID SHINE Laser and reusable ECO Filter last for 20,000 hours9 with no lamp or filter maintenance hassle. With eco-friendly 240 W power consumption that’s 20 %10 lower than conventional lamp-based models, TMZ400 Series supports sustainable projection at lower cost and with less waste.
- 03 Key Feature
Crisp, Sharp Images and Text at WUXGA
With 4,000 lm2, 3,000,000:111 Dynamic Contrast, and Daylight View Basic, TMZ400 Series has power to cut through bright ambient light and deliver sharp, clear pictures. WUXGA1 LCD panels display content at its original aspect ratio and clearly define text for easy visibility.
Project Anywhere Instantly from Short Distances
Clear Pictures, No Shadows
Project an 80-inch image from a distance of just 73 cm1 (2.40 ft) right off your desktop. Thanks to the short-throw-lens, you no longer have to worry if your body is casting a shadow on the screen. The short-throw design is a perfect fit in small rooms, projecting a large 100-inch image without shadows from a distance of 93 cm2 (3.05 ft). With up to 4,000 lm3 of laser brightness, 3,000,000:14 Dynamic Contrast, and WUXGA5 resolution, TMZ400 Series delivers clear, sharp, vivid pictures with lights on and blinds open.
Easy for Everyone to Use
TMZ400 Series combines TV-like convenience with easy portability. Its body width and depth are not much larger than a laptop computer, and it weighs just 4.9 kg (10.8 lbs), light enough to take wherever you need to go, and easy to install on the ceiling. Setup is simple: just set on a desktop, connect the source, and start presenting.
Start Work Instantly
Start your class or meeting instantly without distracting delays that lose the group’s attention. Unlike lamp-based projectors, which take time to start up, TMZ400 Series projects your content about one second1 after powering on from standby thanks to its SOLID SHINE Laser light source. It also features a Direct Off function, so you can turn the projector off any time via the room breaker.
Quiet Operation Keeps People Focused
TMZ400 Series includes a Quiet Mode that reduces operating noise to as little as 24 dB1—the same apparent loudness as rustling leaves. The projector fits unobtrusively into your environment and minimizes distractions even when the group is seated close by the projector. Quiet projection helps keep attention focused on the presentation, whether your class or colleagues are in the room or participating remotely.
Digital Zoom Extender Adds Digital Image Shift Function
Digital Zoom Extender evolves with a new Digital Image Shift function. It provides a convenient workaround when it’s not possible to install the projector at the center of the screen due to light fittings or air-conditioning vents on the ceiling, or in cases where the ceiling is too high. You can digitally shift the image 10% up or down and 10% left or right so it fits on your screen using the projector remote control.
Digital Zoom Extender function allows you to keep the same mount position as your old projector even if it’s too far from the screen, saving construction work. It extends throw-distance past the range of optical zoom so the image is projected at the desired size on your screen. TMZ400 Series uses the same mount and attachment bracket as the conventional lamp-based PT-TW381R Series, so you if you’re updating, you can bolt the new projector straight in and use Digital Zoom Extender to fit the image on screen.
Screen Adjustment with Automatic Vertical Keystone Correction
TMZ400 Series features simple screen adjustment operable by remote control. It includes Automatic Vertical Keystone Correction that fixes trapezoidal distortion when the projector is tilted up or down; 4-Corner and Horizontal/Vertical Keystone Correction to correct the image when projecting at an angle; 6-Point Correction that removes distortion when projecting an image into the corner of a room; and Curved Screen Correction to remove barrel or pincushion distortion when projecting onto curved surfaces.
Note: 6-Point Screen Adjustment available on PT-TMZ400 only.
Efficient Reliability with Minimal Maintenance
Designed for Stress-free Life
Excellent picture quality is just one benefit of laser projection. Both the light source and ECO Filter don’t need to be replaced until about 20,000 hours1. Comparable lamp projectors would need between one and four lamp changes plus filter maintenance if operated for the same amount of time. You also don’t need to worry about disposing of expired lamps, and the ECO Filter can be washed and reused, saving waste. It’s easy to see how laser projection reduces cost and maintenance hassle. And thanks to the light-source’s controlled brightness ramp and consistently uniform color reproduction, images stay clear and vivid for much longer.
Eco-friendly Design Saves You and the Environment
Make the change to eco-friendly Panasonic projection and reduce impact on the environment in line with your organization’s SDGs. TMZ400 Series uses light 1.5 times1 more efficiently than conventional lamp-based models, increasing brightness by about 20%2 while reducing energy consumption by 20%3. Maximum power consumption in NORMAL Mode is just 240 W. These energy savings really add up, especially if you’re operating more than one projector. You can improve energy efficiency even further by setting the projector to ECO or QUIET modes.
Crisp, Sharp Images and Text at WUXGA1
See More Detail in WUXGA1 Resolution
WUXGA1 (1920 x 1200) LCD panels improve text definition and clarify details for a more engaging presentation. With higher panel resolution than Full HD (1920 x 1080) projectors, the PT-TMZ400 can reproduce images at their original aspect ratio and reduce the need to scroll when projecting webpages and spreadsheets thanks to the extra image height.
1 PT-TMZ400: WUXGA (1920 x 1200), PT-TMW380: WXGA (1280 x 800), PT-TMX380: XGA (1024 x 768).
Vivid Image Quality in Well-Lit Rooms
Classroom and office projectors need to be powerful enough to cut through bright ambient light, or the picture looks dull and washed out. Despite its compact body and light 4.9 kg (10.8 lbs) weight, TMZ400 Series packs up to 4,000 lm1 of laser brightness for sharp, well-saturated pictures with the room lights on and blinds open.
Dynamic Contrast Adds Depth and Realism
Dynamic Contrast analyzes the video signal frame-by-frame and digitally adjusts light output according to the contrast requirements of each scene. It features scene-linking technology for greater realism when dark and light scenes frequently interchange. As well as accurate reproduction of images that contain a mix of dark and bright shades, Dynamic Contrast is more energy-efficient than other technologies. The high 3,000,000:11 contrast ratio delivers impressive detail definition in shadows and improves text legibility for more comfortable viewing.
Optimized Images to Suit Your Space
Daylight View Basic optimizes image quality according to the amount of light in the room. A sensor measures ambient brightness and adjusts brightness, dynamic contrast, and color for clearest results in any conditions.
CEC Command-Compatible1 HDMI® Makes Life Easy
Both of the projector’s HDMI inputs are compatible with CEC commands1 for your convenience. The projector will automatically switch on, select an input, play your content, and switch off when it detects these commands from a compatible source device such as a Blu-ray™ player, media streaming dongle, or Panasonic’s optional Wireless Presentation System PressIT2. Get your content playing smoothly and easily using just one remote control.
Supports 4K Input Signals1 for Easy System Integration
TMZ400 Series accepts 4K input signals1 via HDMI. That’s a big help if you plan to distribute 4K content from a media server to various display endpoints around your school or office that have different screen resolutions. You don’t need to manually reencode your video content or use an external video converter, reducing system and workflow complexity.
Project Wirelessly1 from Your Smartphone or Laptop
Share content wirelessly1 from your laptop or smartphone. Just scan the QR code shown in the on-screen display menu using your smartphone’s camera, and your device connects to the projector automatically over wireless LAN, no SSID or passwords required. Then use free Panasonic wireless apps to beam your media to the big screen.
Discover PressIT1, the Simple Wireless Solution
Meeting participants can share their device screens to the projector at the touch of a button. Wireless Presentation System PressIT1 can connect up to 32 devices to the projector at once, and allows your group to display content and switch presenters with a single button-press. PressIT comprises a receiver connected to the projector, and transmitters that connect to PCs or mobile devices2. Make the most of your face-to-face meeting time at a safe social distance. Learn more about PressIT here or visit our Wireless Solutions webpage.
Power Devices via USB Terminal
The projector includes a USB terminal supporting 5 V/2 A DC power supply for the optional Wireless Presentation PressIT1 receiver or a compatible media streaming device2. Reduce cable clutter and avoid the need for an extra AC outlet or outlet adapter on the ceiling.
Auto Input-Switching Function
TMZ400 Series makes everyday operation more convenient. Auto Input-Signal Search function listens for incoming video signals and switches to the correct input automatically without the user having to perform this operation using the projector’s remote control.
Plug-and-Play Projection with Memory Viewer
You don’t need a computer to start presenting—just insert a USB memory stick to the projector’s USB port, press the NETWORK/USB button on the remote, select MEMORY VIEWER, and your still images are displayed. You can advance or go back to the previous slide using the arrow keys.
Multi Monitoring & Control Software with Optional Early Warning Functions
Monitor and control up to 2,048 display devices via LAN. The software enables status monitoring, device control, playlist delivery, playback scheduling, and system-map visualization. A free 90-day trial of optional Early Warning software is included. It notifies the admin of playback or device errors, and sends alerts when symptoms of trouble are detected. The software links with compatible network cameras for live screen-monitoring, and you can monitor devices remotely from a tablet via VPN. Software data can be acquired via Web API and installed onto an existing control application. For more information, visit our software information webpage.
